Carbon Fiber Fabric 4x4 Twill 3k 8.3oz/281gsm Toray T300

Carbon Fiber Fabric — Toray® T300, 3K 4×4 Twill, 8.3 oz (281 gsm), 50″ & 60″ Widths

Woven from genuine Toray T300 3K PAN-based fiber, this specialty 4×4 twill carbon cloth delivers a bold, high-end aesthetic with excellent drape. The tighter, multi-twill repeat creates deep visual depth and a premium “show” finish while maintaining balanced properties for strong, low-void laminates. It is an easy-to-use fabric for hand layup, vacuum bagging, or resin infusion where both appearance and performance matter.

• Fiber / Tow: Toray T300 carbon, 3K
• Weave: 4×4 twill (distinct, premium cosmetic with great conformability)
• Areal Weight: 8.3 oz (281 gsm)
• Widths: 50″ and 60″ (samples available)
• Benefits: Deep twill visual, smooth surface, good drape over complex shapes, tight and uniform weave for clean laminates
• Processes: Hand layup, vacuum bagging, and resin infusion with clear, UV-stable epoxy systems
• Applications: Automotive & motorsports panels, marine parts, consumer products, interiors and trim, sporting goods, and cosmetic skins/veneers

Tips for Best Results

• Use a clear, UV-stable epoxy to showcase the 4×4 twill pattern and protect the cosmetic finish.
• Vacuum consolidation or infusion helps achieve low void content and a crisp, glossy surface.

Sold by the linear yard (36″ length at 50" OR 60" width). Multiple yards ship as one continuous length whenever possible.
