Carbon Fiber Fabric 2x2 Twill 6k 11oz/372gsm Commercial Grade Fabric

Carbon Fiber Fabric – 2x2 Twill • 6K • 11 oz (≈372 gsm) • Commercial Grade

This versatile 6K 2×2 twill carbon fiber cloth delivers the classic carbon look with the drape you want for hand layup, vacuum bagging, and infusion. The commercial-grade construction features a tighter, cleaner weave than many entry-level fabrics, helping you achieve straighter bundles, fewer pinholes, and a better-looking final part at an excellent value. Available in 50″ and 60″ widths for efficient coverage on large panels.

Why builders choose this fabric

• 6K tow / 2×2 twill: balanced strength with easy drape over complex shapes; iconic carbon appearance.
• 11 oz (≈372 gsm): a robust single-ply for general laminating, skins, and cosmetic outer layers.
• Tight commercial weave: improved fiber straightness and cosmetics compared to budget cloths.
• Process-friendly: performs well in hand layup, vacuum bagging, and resin infusion.
• Value & availability: consistent, high-value fabric for production or one-off projects.

Typical applications

• Automotive & motorsport: bodywork, dashboards, interior trim, aero panels, brackets
• Marine & watersports: panels, boards, foils, hatches, instrument housings
• UAV/robotics & consumer products: frames, arms, shells, cases, sporting goods
• Cosmetic skins where a premium 2×2 twill finish is desired

Specifications

• Fiber: Carbon Fiber, 6K tow (standard modulus)
• Weave: 2×2 Twill
• Areal Weight: 11 oz (≈372 gsm)
• Widths: 50″ (127 cm) and 60″ (152.4 cm) nominal
• Recommended Resin: Epoxy (clear, UV-stable epoxy for cosmetic work); compatible with polyester/vinyl ester as project allows
• Processes: Hand layup, vacuum bagging, resin infusion

Layup tips

• Use 2×2 twill as an outer cosmetic ply over structural orientations (0/90° and ±45°) for stiffness and stability.
• Employ peel ply and proper bagging to reduce print-through and pinholes; post-cure per epoxy supplier for best finish.
• For large panels, choose 60″ width to reduce seams and labor.

Sold by the linear yard (36″ length × 50" or 60" width). Continuous yardage ships on one roll when possible.
