Carbon Fiber Fabric Unidirectional 12k 12oz/404gsm
Description
Description
Carbon Fiber Fabric — Unidirectional (UD) · 12k · 12oz (≈404gsm)
This unidirectional (UD) carbon fiber fabric concentrates reinforcement in the 0° (warp) direction for maximum axial stiffness and strength. Produced with reliable 12k tow fibers, the UD bundle is stabilized with a light stitch/cloth thread so it handles cleanly during cutting and layup while keeping resin flow pathways open for vacuum bagging or infusion. It is available in multiple widths—from narrow tape sizes to full-width fabric—so you can tailor ply build-ups for spar caps, stringers, ribs, panels, and structural repairs without waste.
Highlights
- True UD performance: Fibers aligned along the 0° axis for the highest axial properties.
- 12 oz (≈404 gsm): A versatile weight for structural laminates and cap layups.
- Stable handling: Light cross-stitch minimizes fray and keeps the bundle in place during layup.
- Process-friendly: Compatible with epoxy (recommended), vinyl-ester, and polyester resins.
- Multiple widths: Common widths include 1", 1.5", 2", 3", 4", 6", 12", 24", and 50" for efficient ply design.
Typical applications
Spar caps and stringers, UAV/RC wings, marine foils, paddles and oars, skis/boards, bicycle and motorsport laminates, high-stiffness tubes and beams, and local reinforcement of composite panels. Combine with ±45° and 90° plies for balanced laminates and shear control.
Technical data
- Fiber: Carbon fiber, 12k tow (standard modulus)
- Construction: Unidirectional (0° warp) with light stitch/cloth thread binder
- Areal weight: 12 oz (≈404 gsm)
- Nominal thickness: 0.021" (≈0.53 mm)
- Available widths: 1", 1.5", 2", 3", 4", 6", 12", 24", 50" (availability may vary)
- Resin compatibility: Epoxy (preferred), vinyl-ester, polyester
- Processes: Wet layup, vacuum bagging, resin infusion/VARTM
Processing tips
- Align the UD along the primary load path (0°). Add ±45° and 90° plies to control shear and transverse properties.
- Consolidate under vacuum for the best fiber-volume fraction and surface finish.
- For cosmetic parts, finish with a compatible clear coat or paint that provides UV protection.
Sold by the linear yard (36" length x selected width) Multiple yardages ship on one continuous roll when possible.
