Hexcel HexForce Fiberglass E-Glass 8 Harness Satin Weave 8.81oz/299gsm Style 7781 F16 Finish
Description
Hexcel® HexForce® Fiberglass — E-Glass 8-Harness Satin (8HS) · 8.81oz (≈299gsm) · Style 7781 · F16 Finish · 38"/50" Widths
Hexcel® HexForce® Style 7781 is a workhorse E-glass reinforcement that uses an 8-Harness Satin (8HS) weave for outstanding drape over complex curves and an exceptionally smooth surface. At 8.81oz (≈299 gsm) it provides a great balance of conformability and strength, making it a go-to fabric for high-quality cosmetic skins and structural laminates alike. The F16 silane finish promotes fast, thorough wet-out and durable bonding with common composite resin systems.
Why builders choose 7781
- 8HS drape conforms easily to tight radii and compound curves; minimizes bridging and print-through.
- Smooth, tight face yields clean cosmetic laminates and makes an excellent outer ply over heavier reinforcements.
- Versatile weight (≈300 gsm) suited for small parts, skins, and multi-ply layups.
- F16 finish (silane coupling agent) compatible with epoxy, polyester, and vinyl-ester resins.
- Hexcel quality for consistent fiber alignment, uniform finish, and predictable processing.
Typical applications
Cosmetic outer plies, boat & board sheathing, canoe/kayak hulls and decks, fairings and cowlings, aircraft/ UAV skins, panels, racing & powersports parts, and hybrid layups with carbon fiber to improve surface finish.
Specifications
- Manufacturer: Hexcel® HexForce®
- Fiber: E-Glass
- Weave: 8-Harness Satin (8HS)
- Style: 7781
- Finish: F16 (silane) — epoxy/polyester/vinyl-ester compatible
- Areal Weight: 8.81 oz (≈299 gsm)
- Widths: 38 inches (96.5 cm) & 50 inches (127 cm)
Processing notes
- Wets out quickly and transparently; squeegee or use peel-ply to control resin content and minimize print-through.
- Excellent as a final cosmetic ply over heavier fabrics for a smoother paint/clear-coat ready surface.
- Follow your resin manufacturer’s mix ratios and cure schedule. Apply UV-stable paint or clear coat for outdoor exposure.
Ordering
- Width: 50" (127 cm) or 38" (96.5 cm)
- Sold by:Linear Yard — 1 yard = 36" length × full width
- Continuous Lengths: Multiple yards ship as one continuous piece whenever possible.
How We Sell
We sell this fabric by the linear yard. You will receive a continuous piece of fabric at the width listed.
For example, if the fabric is 50" wide, a quantity of 1 (linear yard) equals a continuous piece measuring 50" wide × 36" long. A quantity of 5 (linear yards) equals a continuous piece measuring 50" wide × 180" long.
