Hexcel HexForce Fiberglass E-Glass Plain Weave 3.67oz/124gsm Style 1522 F16 Finish

Hexcel HexForce Fiberglass E-Glass Plain Weave 3.67oz/124gsm – Style 1522 F16 Finish (50"/127cm)

Hexcel HexForce Style 1522 F16 is a premium, lightweight E-glass plain weave fiberglass cloth engineered for applications where low weight, excellent clarity, and smooth surface quality are critical. At approximately 3.67oz (≈124gsm), this fabric is ideal as a surfacing ply, cosmetic layer, or as part of multi-layer laminates that demand high performance with minimal mass.

The plain weave construction and fine yarns provide a tight, uniform fabric that wets out easily and drapes well over subtle curves, resulting in smooth, print-through resistant laminates. Hexcel’s proven F16 finish delivers excellent adhesion with epoxy, vinyl ester, and polyester resin systems, making this style a versatile choice across many composite manufacturing processes.

Key Features

• High-quality Hexcel HexForce E-glass for consistent, reliable performance.
• Lightweight 3.67oz (≈124gsm) design for minimal added weight.
• Plain weave for stability, easy handling, and an even, smooth finish.
• F16 finish compatible with epoxy, vinyl ester, and polyester resins.
• Excellent as a surface veil, cosmetic ply, or outer layer over heavier reinforcements.

• Well-suited to hand lay-up, vacuum bagging, resin infusion, and other processes.

Typical Applications

• Boat building, canoes, kayaks, and marine fairing layers
• Surfboards, skis, snowboards, and sporting goods
• Automotive and motorsport bodywork & aero components
• RC aircraft, UAVs, and lightweight aerospace components
• General-purpose composite skins and cosmetic overlays

Technical Summary

• Fiber Type: E-Glass
• Style: 1522
• Construction: Plain Weave
• Finish: F16
• Fabric Weight: ~3.67oz (≈124gsm)
• Width: 50" (127 cm)
• Resin Compatibility: Epoxy, Vinyl Ester, Polyester

Ordering

• Width: 50" (127 cm)
• Sold by:Linear Yard — 1 yard = 36" length × full width
• Continuous Lengths: Multiple yards ship as one continuous piece whenever possible.

Color & Image Notice: Due to monitor settings, lighting conditions, and production variations, actual fabric shade and appearance may differ slightly from shown images. Performance characteristics remain unaffected.
