TeXtreme® 1005 - HM High Modulus Spread Tow Carbon Fiber 12k 39.37"/100cm 3.83oz/130gsm HS40
Description
Description
TeXtreme® 1005 – HM High Modulus Spread Tow Carbon Fiber, 12k, 39.37"/100 cm, 3.83 oz (130 gsm) – HS40
TeXtreme® 1005 is a high-modulus (HM)spread-tow carbon fiber fabric designed for parts that demand maximum stiffness with an ultra-clean cosmetic finish. TeXtreme® flattens 12k tows into wide tapes and weaves them with minimal crimp, reducing resin-rich pools and fiber waviness versus conventional cloth. At just 130 gsm (3.83 oz), this style delivers a premium checkerboard face ply with outstanding stiffness-to-weight.
Why TeXtreme® HM Spread-Tow?
- High Modulus (HS40) for superior panel stiffness and reduced deflection.
- Low crimp / high fiber straightness for efficient load transfer and better mechanicals.
- Premium cosmetics—tight, flat checkerboard with minimal print-through.
- Lightweight 130 gsm ideal for skins, fairings, and sandwich facesheets.
- Smoother surfaces that often need less finishing compared to standard woven cloth.
Typical Applications
- Motorsport bodywork, aero, floors, and structural panels
- UAV/Drone wings & fuselages, RC models, and aerospace interior panels
- Bike and sporting-goods components where feel/stiffness matters
- Marine overlays and lightweight sandwich skins
- Cosmetic face plies over structural layups
Processing Notes
- Compatible with epoxy (recommended), vinyl ester, and polyester systems.
- Excellent in wet layup, vacuum bagging, and resin infusion.
- HM fibers are stiffer—handle gently and support edges when cutting ultra-light plies.
- Supplied with a light handling/binder finish and protective liner for clean release.
Key Specifications
| Brand / Style | TeXtreme® 1005 – HM Spread Tow (HS40) |
|---|---|
| Tow Size | 12k |
| Areal Weight | 3.83 oz/yd² (130 gsm) |
| Nominal Width | 39.37" (100 cm) |
| Weave | Spread-tow plain (checkerboard) |
| Recommended Resin | Epoxy (room-temp or elevated-temp cure) |
| Best Use | Cosmetic face ply & lightweight stiff skins |
Ordering
- Width: 39.37" (100 cm)
- Sold by:Linear Yard — 1 yard = 36" length × full width
- Continuous Lengths: Multiple yards ship as one continuous piece whenever possible.
Note: Mechanical performance varies with layup schedule, fiber orientation, resin content, and cure. Validate in your application.
