Carbon Fiber Fabric Plain Weave 3k 5.7oz/193gsm Hexcel AS4

Carbon Fiber Fabric — Hexcel® AS4, 3K Plain Weave, 5.7 oz (193 gsm), 50″ Width

Woven from genuine Hexcel AS4 aerospace-grade 3K fiber, this plain-weave carbon cloth delivers high strength, predictable handling, and the classic 3K checkerboard finish. AS4 is a PAN-based, high-strength fiber (~644 ksi tensile) that consolidates into stiff, low-void laminates while maintaining excellent cosmetics—ideal for parts that need both performance and appearance.

• Fiber / Tow: Hexcel AS4 carbon, 3K (high-strength aerospace grade)
• Construction: Balanced plain weave for stable cutting and easy orientation
• Areal Weight: 5.7 oz (193 gsm)
• Width: 50″ (127 cm) — sample swatches available
• Benefits: Tight, uniform weave; strong stiffness-to-weight; smooth cosmetic surface with minimal print-through
• Processes: Hand layup, vacuum bagging, and resin infusion
• Applications: Motorsports and marine panels, UAV/robotics, sporting goods, cosmetic skins, and sandwich facesheets

Tips for Best Results

• Use a clear, UV-stable epoxy for maximum clarity and durability.
• Vacuum consolidation (bagging or infusion) helps achieve flat, low-void laminates.

Sold by the linear yard (36″ × 50″ per yard). Multiple yards ship as one continuous length when possible.
