Airtech Resinflow 60 Resin Flow
Description
Airtech Resinflow® 60 – Resin Flow Media, 60" Width
Resinflow® 60 is a high-performance flow media (distribution mesh) used for vacuum infusion. Placed on top of peel ply, it provides a fast, uniform resin pathway across the laminate, improving wet-out and reducing fill time on large parts. It is easy to cut, drapes well over gentle contours, and works with polyester, vinyl ester, and epoxy systems.
Key Features
- Process: Designed for vacuum infusion – lay over peel ply to distribute resin efficiently.
- Coverage: 60" (152.4 cm) width reduces seams on wide panels and molds.
- Flow performance: Open-mesh structure promotes rapid, even flow and consistent fiber volume.
- Compatible resins: Epoxy, vinyl ester, and polyester.
- Handling: Conformable and easy to position; trims cleanly around ports and edges.
Placement & Use
- Lay over peel ply (or perforated release as specified) and under the vacuum bag.
- Route to vacuum ports and runners to maintain free air/resin pathways.
- Do not use as a substitute for peel ply.
Ordering
- Width: 60" (152cm)
- Sold by: Linear yard — Multiple yards ship as one continuous piece whenever possible.
Shipping note: Due to bulk, orders over 50 yards may ship in multiple boxes.
